| Category |
Specification |
| Lens |
- FOV: Horizontal field of view: 100° to 33° (Wide-Tele), Vertical field of view: 53° to 18° (Wide-Tele), Diagonal field of view: 119° to 37.5° (Wide-Tele).
- Focal Length: 2.8 mm to 12 mm, 4× optical zoom.
- Zoom Speed: Approx. 2 s (optical lens, wide-tele).
- Working Distance: 10 mm to 1500 mm (wide-tele).
- Aperture Range: F1.6 to F2.7.
|
| Smart Features |
- Basic Event Detection: Motion Detection, Video Tampering Detection, Exception.
- Smart Detection: Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection.
- Smart Record: ANR (Automatic Network Replenishment), Dual-VCA.
- ROI: Main stream, sub-stream, and third stream respectively support two fixed areas.
|
| Network |
- Security Measures: User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering.
- Network Storage: Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR.
- Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour.
- API: Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform, support Hik-Connect.
- Simultaneous Live View: Up to 20 channels.
- User/Host: Up to 32 users, 3 levels: Administrator, Operator and User.
- Client: iVMS-4200, HikCentral, HiLookVision.
- Web Browser: IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51.
|
| Image |
- Image Enhancement: 3D DNR, BLC, HLC, EIS, Regional Exposure, Regional Focus.
- Sub-Stream: 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288), 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240).
- Max. Resolution: 2560 × 1440.
- Main Stream: 50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720), 60Hz: 24fps (2560 × 1440), 30fps (2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720).
- Third Stream: 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288), 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240).
|
| Interface |
- Audio Input: 1-ch audio input (line in).
- Audio Output: 1-ch audio output (line out).
- Network Interface: 1 RJ45 10 M/100 M Ethernet, PoE.
- Built-in Microphone: 1 built-in microphone, picking up sounds in the radius up to 5 meters.
|
| Camera Module |
- Image Sensor: 1/3" progressive scan CMOS.
- Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 Lux with IR.
- White Balance: Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp.
- Gain: Auto/Manual.
- Shutter Time: 50Hz: 1/1 s to 1/30,000 s, 60Hz: 1/1 s to 1/30,000 s.
- Day & Night: IR Cut Filter.
- Digital Zoom: 16×.
- Privacy Mask: 24 programmable privacy masks.
- Focus Mode: Auto/Semi-automatic/Manual.
- WDR: 120 dB WDR.
|
| General |
- Material: Aluminum alloy, PC, PC+ABS.
- Dimensions: Φ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00").
- Weight: Approx. 0.53 kg (1.17 lb).
- Protection Level: IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection.
- Power: 12 VDC, 1.5 A (Max. 9.9 W, including max. 4.2 W for IR); PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 11.2 W, including max. 4.2 W for IR).
- Working Temperature: -20°C to 60°C (-4°F to 140°F).
- Working Humidity: ≤ 90%.
|
| Supplement Light |
- IR Distance: 20 m.
- Smart IR: Support.
|
| PTZ |
- Movement Range (Pan): 0° to 330°.
- Pan Speed: Configurable, from 0.1°/s to 100°/s, Preset speed: 100°/s.
- Movement Range (Tilt): From 0° to 90°.
- Tilt Speed: Configurable, from 0.1°/s to 100°/s, Preset Speed: 100°/s.
- Proportional Zoom: Support.
- Presets: 300.
- Power-off Memory: Support.
|
| Compression Standard |
- H.264+: Support.
- H.265+: Support.
- H.264 Type: Baseline Profile/Main Profile/High Profile.
- Video Compression: Main Stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third Stream: H.265/H.264/MJPEG.
- H.265 Type: Main Profile.
- Video Bitrate: 32 Kbps to 16384 Kbps.
- Audio Compression: G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM.
- Audio Bitrate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2).
- SVC: Support.
|
