| Category |
Specifications |
| Lens |
- FOV: Horizontal: 120° to 56.6°, Vertical: 61.8° to 31.7°, Diagonal: 149° to 65°
- Focal Length: 2.8 mm to 12 mm, 4× optical zoom
- Zoom Speed: Approx. 5.4 s (wide - tele)
- Working Distance: 10 mm to 1500 mm
- Aperture Range: F2.0 to F2.4
|
| Smart Features |
- Basic Event Detection: Motion Detection, Video Tampering Detection, Exception
- Smart Detection: Audio Exception Detection, Intrusion Detection, Line Crossing Detection
- Smart Record: ANR (Automatic Network Replenishment)
- ROI: Main stream supports eight fixed areas
- Smart Image Enhancement: HLC/BLC/3D DNR/Regional Exposure/Regional Focus
|
| Network |
- Security Measures: User authentication, Host authentication, HTTPS encryption, IEEE 802.1x, IP address filtering
- Network Storage: Micro SD/SDHC/SDXC, up to 256 GB
- Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
- API: ONVIF, ISAPI, CGI, HIKVISION SDK, Third-Party Management Platform
- Simultaneous Live View: Up to 4 × 4 channels
|
| Image |
- Max. Resolution: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, etc.), 60 Hz: 30 fps (1920 × 1080, 1280 × 720, etc.)
- Interface: 1-ch audio input, 1-ch audio output, 1 RJ45 10 M/100 M Ethernet
- Dual-VCA: Supported
|
| Camera Module |
- Image Sensor: 1/2.8" progressive scan CMOS
- Min. Illumination: Color: 0.05 Lux, B/W: 0.01 Lux, 0 Lux with IR
- White Balance: Auto/Manual/ATW/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
- Gain: Auto/Manual
- Shutter Time: 50 Hz: 1/25 s to 1/30,000 s, 60 Hz: 1/30 s to 1/30,000 s
- Day & Night: IR Cut Filter
- Digital Zoom: 8×
- Privacy Mask: 8 programmable privacy masks
- Focus Mode: Semi-automatic/Manual
- WDR: Digital WDR
|
| General |
- Material: PC + ABS & Aluminum alloy
- Dimensions: Φ 183 mm × 133 mm
- Weight: Approx. 0.9 kg
- Protection Level: TVS 2000V Lightning Protection, Surge Protection, Voltage Transient Protection
- Power: 12 VDC, 2.0 A & PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, class 4, Max. 24 W (Max. 6 W for IR)
- Working Temperature: -10°C to 50°C
- Working Humidity: ≤ 90%
- Supplement Light: IR Distance: Up to 10 m IR (radius)
|
| PTZ |
- Movement Range (Pan): 0° to 350°
- Pan Speed: 0.1°/s to 30°/s (configurable), preset speed: 30°/s
- Movement Range (Tilt): 0° to 90°
- Tilt Speed: 0.1°/s to 30°/s (configurable), preset speed: 30°/s
- Proportional Zoom: Supported
- Presets: 300
- Power-off Memory: Supported
- PTZ Status Display: Supported
- Preset Freezing: Supported
- Scheduled Task: Preset/Dome Reboot/Dome Adjust
- PTZ Linkage: Supported
|
| Compression Standard |
- Video Compression: H.265/H.264/MJPEG, H.264: Main Profile/High Profile
- Video Bitrate: 32 Kbps to 8192 Kbps
- Audio Compression: G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2
- Audio Bitrate: G.711alaw/G.711ulaw: 64 Kbps, G.722.1/G.726: 16 Kbps, MP212: 32 Kbps/64 Kbps/128 Kbps
- SVC: Supported
|
