| Category |
Specification |
| Camera |
- Image Sensor: 1/2.8" progressive scan CMOS.
- Max. Resolution: 1920 × 1080.
- Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 Lux with IR.
- Shutter Speed: 1/1 s to 1/30,000 s.
- Day & Night: IR Cut Filter.
- Zoom: 15x optical, 16x digital.
|
| Lens |
- Focal Length: 5 mm to 75 mm, 15× optical.
- FOV: Horizontal field of view: 53.8° to 4.0° (wide-tele), Vertical field of view: 31.9° to 2.3° (wide-tele), Diagonal field of view: 60.4° to 4.6° (wide-tele).
- Focus: Auto, semi-auto, manual.
- Aperture: F1.6 to F3.0.
- Zoom Speed: Approx. 2.4 s (optical lens, wide-tele).
|
| Illuminator |
- Supplement Light Type: IR.
- Supplement Light Range: Up to 100 m.
- Smart Supplement Light: Yes.
|
| PTZ |
- Movement Range (Pan): 360° endless.
- Movement Range (Tilt): From -15° to 90° (Auto-flip).
- Pan Speed: Configurable, from 0.1°/s to 80°/s, Preset Speed: 80°/s.
- Tilt Speed: Configurable, from 0.1°/s to 80°/s, Preset Speed: 80°/s.
- Proportional Pan: Yes.
- Presets: 300.
- Preset Freezing: Yes.
- Patrol Scan: 8 patrols, up to 32 presets for each patrol.
- Pattern Scan: 4 pattern scans, record time over 10 minutes for each scan.
- Park Action: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan.
- PTZ Status Display: Yes.
- Scheduled Task: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust.
- Power-off Memory: Yes.
|
| Video |
- Main Stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720), 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720).
- Sub-Stream: 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288), 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240).
- Third Stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240).
- Video Compression: Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264/MJPEG, Third Stream: H.265/H.264/MJPEG.
- Video Bit Rate: 32 Kbps to 16384 Kbps.
- H.264 Type: Baseline Profile/Main Profile/High Profile.
- H.265 Type: Main Profile.
- Scalable Video Coding (SVC): H.264 and H.265 encoding.
- Region of Interest (ROI): Main stream, sub-stream and third stream respectively support four fixed areas.
|
| Network |
- Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets.
- Simultaneous Live View: Up to 20 channels.
- API: Open Network Video Interface, ISAPI, SDK, ISUP.
- User/Host: Up to 32 users. 3 levels: Administrator, Operator and User.
- Security: User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering.
- Network Storage: NAS (NPS, SMB/ CIPS), ANR.
- Client: iVMS-4200, HiLookVision.
- Web Browser: IE10-11, Chrome 57+, Firefox 52+, Safari 12+.
|
| Image |
- Image Settings: Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser.
- Wide Dynamic Range (WDR): 120 dB.
- Defog: Digital defog.
- Image Stabilization: No.
- Image Enhancement: BLC, HLC, 3D DNR.
- Privacy Mask: 24 programmable privacy masks.
- Regional Focus: Yes.
- Regional Exposure: Yes.
|
| Interface |
- Ethernet Interface: 1 RJ45 10 M/100 M Ethernet Interface; PoE (802.3 at, class4).
- On-board Storage: Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB.
|
| Event |
- Basic Event: Motion Detection, Video Tampering Detection, Exception Detection.
- Smart Event: Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection.
|
| General |
- Power: 12 VDC, 2.0 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A, class4. Max.:18 W (IR Max.6 W).
- Dimension: Ø 165.9 mm × 290 mm (Ø 6.53" × 11.42").
- Weight: Approx. 2.5 kg (5.51 lb).
- Material: ADC 12, PC+10% GF.
- Operating Condition: -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing).
|
| Approval |
- EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7); KC (KN 32: 2015, KN 35: 2015).
- Safety: UL (UL 62368-1); CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252(Part 1):2010/ IEC 60950-1: 2005); LOA (IEC/EN 60950-1).
- Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006).
- Protection: IP66 (IEC 60529-2013), 4000V Lightning Protection, Surge Protection and Voltage Transient Protection.
|
