| Camera | |
|---|---|
| Image Sensor | 2 MP CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Signal System | PAL/NTSC |
| Frame Rate | TVI: 1080p@25fps/30fps CVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVBS: PAL/NTSC |
| Min. Illumination | 0.001 Lux @ (F1.0, AGC ON) 0 Lux with white light |
| Shutter Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
| Lens Mount | M12 |
| Light Alarm | Solid Light Alarm (White Light) |
| Day & Night | 24/7 Color Imaging |
| Angle Adjustment | Pan: 0° to 360° Tilt: 0° to 75° Rotation: 0° to 360° |
| Lens | |
| Lens Type | 2.8 mm/3.6 mm fixed focal lens |
| Focal Length & FOV | 2.8 mm: Horizontal FOV: 102° Vertical FOV: 54° Diagonal FOV: 121° 3.6 mm: Horizontal FOV: 80° Vertical FOV: 43° Diagonal FOV: 95° |
| Illuminator | |
| Supplement Light Type | White Light |
| Image | |
| Image Parameters Switch | STD/HIGH-SAT/HIGHLIGHT |
| Image Settings | Brightness; Contrast; Mirror; Defective Pixel Correction; Sharpness; Anti-Banding; Smart Light |
| Wide Dynamic Range (WDR) | Digital WDR |
| Image Enhancement | DWDR; BLC; HLC; Global |
| White Light | Auto/Off |
| AGC | Yes |
| Day/Night Mode | Color |
| White Balance | Auto/Manual |
| Noise Reduction | 3D DNR/2D DNR |
| Language | English |
| Interface | |
| Video Output | Switchable TVI/AHD/CVI/CVBS |
| General | |
| Operating Condition | -40°C to 60°C (-40°F to 140°F) Humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC ±25% *Use one power adapter per camera |
| Consumption | Max. 4 W |
| Material | Metal |
| White Light Range | Up to 40 m |
| Dimension | Φ 127.92 mm × 100.97 mm (Φ 5.04" × 3.98") |
| Weight | Approx. 478.5 g (1.05 lb.) |
| Approval | Protection IP66 |
Model
THC-T229-M
Camera Lens
2.8mm
Dynamic Range
DIgital WDR
IR Range
UP TO 40m white light
Material
Metal Body
Protection
IP66
Resolution
2MP
Type
Fixed Lens Turret
