| Camera | |
|---|---|
| Image Sensor | 2 MP CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Min. Illumination | 0.005 Lux@(F2.0, AGC ON) 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0° to 360° Tilt: 0° to 180° Rotation: 0° to 360° |
| Signal System | PAL/NTSC |
| Lens | |
| Lens Type | Fixed focal lens, 2.8 mm Varifocal lens, motor-driven lens, 3.6 mm Varifocal lens, manual adjustment, 6 mm |
| Focal Length & FOV | 106° (2.8 mm) 82° (3.6 mm) 51° (6 mm) |
| Lens Mount | M12 |
| Illuminator | |
| Supplement Light Range | Up to 30 m |
| Image | |
| Image Parameters Switch | STD/HIGH-SAT |
| Image Settings | Brightness; Sharpness; Mirror; Smart IR; AGC |
| Frame Rate | PAL: 1080p@25fps NTSC: 1080p@30fps |
| Day/Night Mode | Auto/Color/BW (Black and White) |
| Wide Dynamic Range (WDR) | ≥120 dB |
| Image Enhancement | HLC; BLC |
| Noise Reduction | 3D DNR |
| Supplement Detection (PIR) | PIR Range: Up to 50 m |
| Interface | |
| Video Output | Switchable TVI/AHD/CVI/CVBS; 1 HD analog output |
| General | |
| Power | 12 VDC ±25%, max. 5.6 W |
| Material | Metal |
| Dimension | 75.4 mm × 230.8 mm × 87.2 mm (2.97" × 9.09" × 3.43") |
| Weight | Approx. 550 g (1.21 lb.) |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F) Humidity: 90% or less (non-condensation) |
| Language | English |
| Approval | Protection IP66 |
Model
THC-B229-M
Camera Lens
2.8mm
Dynamic Range
WDR 120dB
IR Range
40m White Light
Material
Metal Body
Protection
IP66
Resolution
2MP
Type
Bullet Camera
